1N4007 General Purpose Rectifier Diode 1000V

Description Type: The 1N4007 is a rectifier diode, commonly used for converting alternating current (AC) to direct current (DC) in power supplies and other electronic circuits. Voltage Rating: It has a maximum repetitive peak reverse voltage (VRRM) of 1000 volts, meaning it can withstand up to 1000V in reverse bias without breaking down. Current Rating: The diode is rated for a forward average rectified current (IF(AV)) of 1 ampere, making it suitable for low to moderate power applications. Package Type: The “Through Hole” designation indicates that the diode is designed to be soldered onto a circuit board with leads passing through holes in the board for mounting. Physical Characteristics: The 1N4007 typically comes in a cylindrical package with two leads (anode and cathode) emerging from one end. Its dimensions are standardized for compatibility with various circuit designs. Construction: It is constructed using silicon semiconductor material, offering good electrical properties such as low forward voltage drop and high reverse voltage blocking capability. Applications: Due to its high voltage and current ratings, the 1N4007 finds application in a wide range of circuits including power supplies, battery chargers, voltage regulators, and rectifiers in various electronic devices. Temperature Range: The diode is designed to operate over a wide temperature range, typically from -65°C to 175°C, ensuring reliability under different environmental conditions. Reverse Recovery Time: The 1N4007 has a relatively slow reverse recovery time compared to some other diodes, which may limit its use in high-frequency applications but makes it more suitable for general-purpose rectification. Power Rectifier Diode Symbol Technical Details Mounting Type: Through Hole Package Type: DO-204AL Maximum Continuous Forward Current: 1A Peak Reverse Repetitive Voltage: 1000V Diode Configuration: Single Series: 1N4007 Rectifier Type: General Purpose Diode Type: Rectifier Pin Count: 2 Maximum Forward Voltage Drop: 1.1V Number of Elements per Chip: 1 Diode Technology: Silicon Junction Diameter: 2.7mm Peak Non-Repetitive Forward Surge Current: 45A
